WDMX Ultra

WDMX Ultra - Wireless ATM Solution with Direct Connection and Encryption.
Be the first to review this product

Call for pricing

Ask for price
Email a friend
Question about product?

The WDMX Wireless adapter is designed to pass the Dial-up or TCP/IP-ATM Machine data via the TCP/IP network with the SSL 3.1/TLS 1.2 encryption. The main features are:

  • Direct connection to a transaction processing company. No intermediate connection to any server, switch, routers or proxy servers.
  • Using the quad-band GPRS/EDGE cellular wireless module approved for the Electronic Point-Of-Sale in Canadian and U.S. markets.
  • High secured SSL 3.1 and TLS 1.2 connection.
  • Supports ATMs with the telephone line communication standards:
    • V.22bis, V.22/Bell212, V.21/Bell103
    • V.23 – 1200/75bps, Bell202 – 1200bps
    • Leased line mode and fast connect
  • Dial phone number auto detection. By dialed phone number the ATM wireless adapter selects the transaction processing company to call.
  • The Support Server to monitor and control the ATM wireless adapter.
  • Automatic, highly secured firmware updates via the Support Server. Firmware is encrypted using the SSL 3.1 and the additional AES 256 cipher algorithm.
Modem Port POTS Line, RJ-11, 2400/1200 baud
Ethernet Port 10/100 Mbit/sec. Straight or cross cable auto detection
Antenna connector SMA female connector
Power Port Power Jack, 5V DC, 3A, 15W, center positive
Network Services HSUPA/HSDPA/GSM/EDGE Quad band GSM or CDMA
LED Indicators GSM Signal Straight; Power OK; Modem, TCP/IP and GSM Ready
Dimensions 140 x 60 x 30 mm
Operating Temp -20 to 45 °C
Weight 550 grams
